33
BASE INSTALLATION WITH VEHICLE SEAT BELT
Lap/Shoulder Belt Routing Method
LEVEL
WHEN
NO RED
VISIBL
E
LE
VE
L WHE
N
NO RED
VISIBLE
5
4 While holding taut, slide shoulder belt back through the
belt path as close as possible to the top of the lock-o.
NOTE: Tightness indicator should be GREEN.
5 Close the top section of the lock-o over the lap/shoul-
der belt
1
. Second, close the bottom section of the
lock-o over the belt . Make sure you push the
bottom of the lock-o all the way down until you hear
an audible click.
L
EVEL
WHEN
NO R
ED
VISIBLE
LEVEL WH
EN
NO RED
VISI
BLE
REVIEW SAFETY CHECK ON PAGE 38.
ALL STEPS MUST BE ACHIEVED.
4
To Next Page
