Maintenance
113100-000 | MX15 / MX19 - Operator Manual Page 11
H
YDRAULIC
F
LUID
Figure 9:
Hydraulic Reservoir
Check the level of the hydraulic
fluid with the platform fully lowered.
The hydraulic reservoir is located
at the rear of the machine. The fluid
level should be visible through the
side of the reservoir, and must be
between the MIN and MAX lines
(see Figure 9). Add hydraulic fluid if
necessary.
B
ATTERY
M
AINTENANCE
WARNING
!
!
Hazard of explosive gas mixture. Keep sparks, flame, and smoking material away from batteries.
Always wear safety glasses when working near batteries.
Battery fluid is highly corrosive. Thoroughly rinse away any spilled fluid with clean water.
Always replace batteries with UpRight batteries or manufacturer approved replacements weighing
26,3 kg (58 lbs.) each.
• Check the battery fluid level daily, especially if the machine is being used in a warm, dry climate.
• If electrolyte level is lower than 10 mm
(
3
/
8
in.) above the plates add distilled water only. DO NOT use
tap water with high mineral content, as it will shorten battery life.
• Keep the terminals and tops of the batteries clean.
• Refer to the Service Manual to extend battery life and for complete service instructions.
