Introduction

113100-000 | MX15 / MX19 - Operator Manual Page 3

NTRODUCTION

This manual covers the application of the MX15 and MX19 Aerial Work Platforms. This manual must be

stored on the machine at all times.

Read, understand and follow all safety rules and operating instructions before attempting to operate the

machine.

ENERAL

ESCRIPTION

WARNING

DO NOT use the machine

if all guardrails are not properly in place and secured

Figure 1:

MX Series

1. Platform Controls

2. Manual Case

3. Deck Extension

4. Platform

5. Elevating

Assembly

6. Chassis

7. Batteries

8. Charger Outlet

Plug

9. Chassis Controls

10. Emergency

Lowering Valve

Knob

11. Hydraulic Fluid

Reservoir

12. Lift Cylinder

13. Level Sensor

(inside chassis)

14. Depression

Mechanism

Support

FRONT

Inside

Chassis
