Upright NX15 Service Manual

Daily Inspection and Maintenance Schedule
113100-000 | MX15 / MX19 - Operator Manual Page 13
D
AILY
I
NSPECTION AND
M
AINTENANCE
S
CHEDULE
The Complete Inspection consists of periodic visual and operational checks, along with periodic minor
adjustments that assure proper performance. Daily inspection will prevent abnormal wear and prolong the
life of all systems. Perform the inspection and maintenance items daily. Inspection and maintenance shall
be performed by personnel who are trained and familiar with mechanical and electrical procedures.
WARNING
!
!
Before performing preventative maintenance, familiarize yourself with the operation of the machine.
Always block the elevating assembly whenever it is necessary to perform maintenance while the
platform is elevated.
The daily preventative maintenance checklist has been designed for machine service and maintenance.
Please photocopy the Daily Preventative Maintenance Checklist and use the checklist when inspecting the
machine.
D
AILY
P
REVENTATIVE
M
AINTENANCE
C
HECKLIST
M AINTENANCE T ABLE K EY
Y = Yes/Acceptable
N = No/Not Acceptable
R = Repaired/Acceptable
P REVENTATIVE M AINTENANCE R EPORT
Date: ______________________________________
Owner: _____________________________________
Model No:___________________________________
Serial No: ___________________________________
Serviced By:_________________________________
COMPONENT INSPECTION OR SERVICES Y N R
Battery
Check electrolyte level.
Check battery cable condition.
Chassis
Check hoses for pinch or rubbing points.
Check welds for cracks.
Control Cable
Check the exterior of the cable for pinching,
binding or wear.
Controller Check switch operation.
Drive Motors Check for operation and leaks.
Elevating Assembly Inspect for structural cracks.
Emergency
Lowering System
Operate the emergency lowering valve and check
for serviceability.
Entire Unit Check for and repair collision damage.
Hydraulic Fluid Check fluid level.
Hydraulic Pump Check for hose fitting leaks.
Hydraulic System Check for leaks.
Labels
Check for peeling, missing, or unreadable labels &
replace.
Platform Deck and
Rails
Check welds for cracks.
Check condition of deck.
Tires Check for damage.
COMPONENT INSPECTION OR SERVICES Y N R
