US Cutter MH-721 - Detail of Carriage Arm; Right Side View

- 5 -
Detail of Carriage Arm
Right Side View
Blade Carriage Slot
(Back Slot)
Holds the Blade Carriage in
place.
Pen Carriage Slot
(Front Slot)
Holds the Pen Carriage in
place.
Locking Knob
Allows access to the
Blade/Pen Carriage Slots for
exchanging/replacing
Carriages.
USB Cable Port
Used to connect a USB
cable from the cutter to
a computer.
Serial (COM) Cable Port
Used to connect a serial
cable from the cutter to
a computer.
Only one of the connection cables should be used to connect
the cutter to a computer. Not both.
