US Cutter MH-721 - Left Side View; Back View of the Cutter

- 6 -
Left Side View
Back View
Pinch Rollers
Holds the media tightly to the feed roller below. Back view shown in detail on next
page.
Power Cable Port
Used to connect a power
cable from the cutter to a
wall outlet or surge
protector.
Power Switch
Main power switch for
turning the power of the
cutter on(1) or off(0).
Fuse Cartridge
Allows access to the fuse
inside of the cutter.
