US Cutter MH-721 - Detail of Pinch Roller Mechanism

- 7 -
Detail of Pinch Roller (Back View)
Pinch Roller Tension
Knobs
Adjusts the tension of how tightly
the pinch roller is held to the feed
roller below.
Pinch Roller Release
Lever
Allows you to release Pinch Rollers
(either so they can be moved from side
to side or to allow media to be easily fed
below them) by pulling up on the
Release Levers.
