Reference
Valves: Sprint iQ contains modular solenoid valves that direct
the flow of air through the measurement circuits. The
number, type, and arrangement of valves in a Sprint tester
is dependant on the model and configuration.
Vent : After Sprint iQ completes a decay test, a valve can be
activated to open the product and Sprint’s internal test
circuit to atmosphere. The action of releasing pressure to
atmosphere is called vent. If vent is not required (for
instance, if you want to unplug product to vent pressure),
set Vent to No.
Venturi, Electronic: This option is used to produce a vacuum
level and requires an inlet pressure between 55.0 to 101.5
psi depending upon the vacuum required. This option is
only available when the Fairchild 120 psi regulator is used
as the Main test regulator. To support this option the
pneumatic arrangement is configured to use the pneumatic
regulator output via the main regulator selection valve
when pressure is required by the test or connects output to
the venturi input when vacuum is required by the test.
