Quick Start
7
2.2 Front Panel Features
The front panel has an LCD display, keypad, Lockout keyswitch,
USB port, and Stop and Start buttons.
Display. The Sprint iQ has a 5.7" diagonal 320 x 240 color
graphic liquid crystal display (LCD) with backlight.
Keypad. The keypad has 6 keys:
• Exit. Use the Exit key to exit the Run
Mode Options Menu mode and return
to the Run display. It is also an
“escape” key, allowing parameter entry
to be aborted without saving changes.
2
