5.0.4 Digital I/O Pin Assignments
Digital I/O is an
optional feature. The
connector may be
found in the location
shown on page 10.
The inputs are
single-ended.
The outputs are 24V
dry-contact relay
operated.
Function Pin No.
START (+) 1
START ENABLE (+) 20
RESET (+) 2
BCD 0 (+) 21
BCD 1 (+) 3
BCD 2 (+) 22
BCD 3 (+) 4
BCD 4 (+) 23
BCD 5 (+) 5
BCD 6 (+) 24
BCD 7 (+) 6
INPUTS RETURN (-) 25
PASS 1 + 7
PASS 1 - 26
FAIL 1 + 8
FAIL 1 - 27
PASS 2 + 9
PASS 2 - 28
FAIL 2 + 10
FAIL 2 - 29
PASS 3 + 11
PASS 3 - 30
FAIL 3 + 12
FAIL 3 - 31
PASS 4 + 13
PASS 4 - 32
FAIL 4 + 14
FAIL 4 - 33
READY + 15
READY - 34
EOC + 16
EOC - 35
ALARM + 17
ALARM - 36
N/C 18
N/C 37
N/C 19
