6
Quick Start
2.1.1 Sprint iQ Requires Clean Dry Air
Before connecting air (or other gas) to Sprint iQ, make certain the
supply air is clean and dry and pressure doesn’t exceed the
maximum input listed on the rear panel.
Supply air is connected to the 1/8-inch female NPT bulkhead on
the back of Sprint iQ.
Compressor
Step-down regulator
Mist and Particulate Filter
Sprint iQ
Water vapor, particulates, and excessive pressure can damage
Sprint iQ’s internal components and affect product testing
2
3
4
