Programming 63
The figure to the right
shows a typical back-
pressure flow test in
which the part passes the
evaluation. In this
example, the residual
back-pressure seen at the
part’s inlet (while the
outlet is vented to
atmosphere) was within
the established reject
minimum and reject
maximum limits, indicating that the passage was the correct size.
