68
Programming
linked test in the series as long as the product passed all
tests.
8. At the end of all linked tests, the operator (or automated
machinery) removes the product and Sprint iQ is ready to
begin the next test.
The product is pressurized during fill time, and the pressure is not
able to rise above the pressure error limit. The test part’s flow
path is open to atmosphere throughout the test.
Test pressure is set while flowing
When setting the test pressure a known good part is used rather
than simply blocking the test port. By flowing through a part the
pressure can be set at the level expected when the flow path is
open.
Fill Time Occlusion Test Pass
The significant flow through product keeps the test pressure from
rising and thus is not blocked.
Fill Time Occlusion Test Fail
If the flow path were to be blocked, the test pressure will rise
indicating that the flow path is blocked. The test will fail in the fill
time because the pressure is above the pressure error limit.
