Utax 5240L

Part Names
1-6
26 Top Cover
27 Original Width Guides
28 Original Table
29 Original Eject Table
30 Original Stopper
31 Document Processor Open/Close Handle
32 USB interface Connector
33 Network Interface Connector/indicators
34 LINE Connector*
35 TEL Connector*
36 Rear Cover
37 Power Cord Connector
38 Main Power Switch
39 Handholes
40 Left Cover
41 Waste Toner Box
*Only on products with the fax function installed.
