Utax P-4035 MFP Service Manual

2NM/2NX/2NY/2NZ/2P0/2P6-1
1-3-56
Codes Description Corrective Action
08 Black band is not detected (DP main scan-
ning direction far end)
1. Check the attachment position of
DP.
2. Check a lighting of the lamp or
replace.
3. Check the back and front of an
adjustment original.
09 Black band is not detected (DP main scan-
ning direction near end)
0a Black band is not detected (DP auxiliary
scanning direction leading edge)
0b Black band is not detected (DP auxiliary
scanning direction leading edge original
check)
0c Black band is not detected (DP auxiliary
scanning direction trailing edge)
0d White band is not detected (DP auxiliary
scanning direction trailing edge)
0e DMA time out Turn the power supply OFF/ON and
performed again.
0f Auxiliary scanning direction magnification
error
1. Turn the power supply OFF/ON
and performed again.
2. Adjust the below items in manual
operation.
(U065 to U067, U070 to U072)
10 Auxiliary scanning direction leading edge
error
11 Auxiliary scanning direction trailing edge
error
12 DP uxiliary scanning direction skew error
13 Maintenance request error Turn the power supply OFF/ON and
performed again.
14 Main scanning direction center line error 1. Turn the power supply OFF/ON
and performed again.
Adjust the below items in manual
operation.
(U065 to U067, U070 to U072)
15 DP main scanning direction skew error
16 Main scanning direction magnification error
17 Service call error Turn the power supply OFF/ON and
performed again.
18 DP paper misfeed error Set the original correctly and per-
form again.
19 PWB replacement error -
1a Original error 1. Clean the contact glass and slit
glass.
2. Exchange the adjustment origi-
nal.
1b Input gamma adjustment original error Set the original correctly and per-
form again.
1c Matrix adjustment original error
1d Original for the white reference compensa-
tion coefficient error

Utax P-4035 MFP Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	600 x 600 DPI
Time to first page (black, normal)	9 s
Print speed (black, normal quality, A4/US Letter)	40 ppm
Duplex print speed (black, normal quality, A4/US Letter)	20 ppm
Copier resize	25 - 400 %
Maximum number of copies	999 copies
Copy speed (black, normal quality, A4)	40 cpm
Scan to	E-mail, File, Image, USB
Grayscale levels	256
Image formats supported	JPG, TIF
Document formats supported	PDF, XPS
Faxing	Mono faxing
Fax memory	8 MB
Modem speed	33.6 Kbit/s
Fax coding methods	JBIG, MH, MMR (Fax coding method), MR
Fax resolution (black)	200 x 100 DPI
Fax transmission speed	3 sec/page
Digital sender	-
Printing colors	Black
Maximum duty cycle	- pages per month
Total input capacity	500 sheets
Total output capacity	250 sheets
Duplex media weight	60 - 120 g/m²
Paper tray media types	Envelopes
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Product color	Black, Grey
Market positioning	Business
Wi-Fi	No
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Mobile printing technologies	Apple AirPrint
Standard interfaces	Ethernet, USB 2.0
Memory slots	1
Internal memory	512 MB
Compatible memory cards	SD
Sound power level (standby)	53 dB
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Power consumption (standby)	54.7 W
Power consumption (average operating)	680 W

Weight and Dimensions

Depth	455 mm
Width	475 mm
Height	575 mm
Weight	21500 g
