2NM/2NX/2NY/2NZ/2P0/2P6
1-5-39
(1-2) Detaching and refitting the separation needle holder
Procedure
1. Remove the transfer roller unit.
2. Release four hooks of separation nee-
dle unit by rotating and then remove the
separation needle unit upward.
3. Check or replace the separation needle
unit and refit all the removed parts.
Caution: Check certainly being fixed at the
time of attachment.
Figure 1-5-65
Separation needle unit
Hooks
To Next Page
