Utax P-4035 MFP Service Manual

2NM/2NX/2NY/2NZ/2P0/2P6
1-4-15
(3) Paper jam at feeding from cassette 1
Electrical parts that could cause paper jam during paper travelling at the primary
feeding (to regist roller)
Timing of detection
Measures
*2: 50/60 ppm model only
Jam code
J0501, J0511, J4101 *2, J4111 *2
Related parts
Registration sensor (RS) Control PWB (CONPWB)
Paper feed clutch (PFCL) Drum PWB (DRPWB) *2
Main motor(MM) Connect right PWB (C-RPWB)
Checking
procedure at the
occurrence of
J0501/J502
J4101/J4111 *2
Corrective action at the occurrence
On/Off control signal output connector
(terminal), point of checking connection
1 Items for Initial Checks See page 1-4-9
2 Registration sensor (RS): Conduct
connectivity check, mounting location
check, operation check
CONPWB YC19-12
D-RPWB YC6-2 *2
3 Control PWB: Replace
4 Drum PWB: Replace *2
5 Paper feed clutch (PFCL): Operation
check
C-RPWB YC12-4
6 Main motor : Operation check
C-RPWB YC10-1/2/3/4
7 Connect right PWB: Replace

Utax P-4035 MFP Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	600 x 600 DPI
Time to first page (black, normal)	9 s
Print speed (black, normal quality, A4/US Letter)	40 ppm
Duplex print speed (black, normal quality, A4/US Letter)	20 ppm
Copier resize	25 - 400 %
Maximum number of copies	999 copies
Copy speed (black, normal quality, A4)	40 cpm
Scan to	E-mail, File, Image, USB
Grayscale levels	256
Image formats supported	JPG, TIF
Document formats supported	PDF, XPS
Faxing	Mono faxing
Fax memory	8 MB
Modem speed	33.6 Kbit/s
Fax coding methods	JBIG, MH, MMR (Fax coding method), MR
Fax resolution (black)	200 x 100 DPI
Fax transmission speed	3 sec/page
Digital sender	-
Printing colors	Black
Maximum duty cycle	- pages per month
Total input capacity	500 sheets
Total output capacity	250 sheets
Duplex media weight	60 - 120 g/m²
Paper tray media types	Envelopes
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Product color	Black, Grey
Market positioning	Business
Wi-Fi	No
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Mobile printing technologies	Apple AirPrint
Standard interfaces	Ethernet, USB 2.0
Memory slots	1
Internal memory	512 MB
Compatible memory cards	SD
Sound power level (standby)	53 dB
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Power consumption (standby)	54.7 W
Power consumption (average operating)	680 W

Weight and Dimensions

Depth	455 mm
Width	475 mm
Height	575 mm
Weight	21500 g
