Utax P-4035 MFP Service Manual

2NM/2NX/2NY/2NZ/2P0/2P6
1-4-64
(11) The leading edge of the image is consistently misaligned with the original.
1. Table scanning
2. DP-scanning
Print example
Defective part Check description Corrective Action
1
Original document Check if the original document is
loaded correctly on the contact
glass.
If the original document is not properly placed
on the contact glass, place it correctly.
2
Secures the lamp
unit
Confirm the oriention of the
bracket that secures the drive
belt and the lamp unit.
If the bracket that fixes the drive belt and the
lamp unit is misaligned, align the bracket
properly.
3
Adjustment of the
scanner
Check the scanning adjustment
of the scanner.
1. Perform maintenance mode U066, Front.
(see page 1-3-29)
2. Perform maintenance mode U411,
table(Chart1)_Input. (see page 1-3-54)
4
Home position sen-
sor
Check the location the home
position sensor is mounted.
Re-mount the home position sensor if it is
hanged off.
5
Drive belt Check if the tension of the drive
belt is insufficient.
If the tension of the drive belt is insufficient,
tense the belt.
6
Scanner drive pul-
ley
Check if the scanner drive pulley
is loosely fixed.
If the scanner drive pulley is loosely fixed,
secure the screws.
Defective part Check description Corrective Action
1
Adjustment of the
scanner
Check the scanning adjustment
of DP scanning.
1. Perform maintenance mode U071, CCD
Head. (see page 1-3-33)
2. Perform maintenance mode U411,
FaceUp(Chart2)_Input. (see page 1-3-54)
2
Original conveying
roller
Check if the conveyer roller is
contaminated or worn.
If the conveying roller is dirty, clean the con-
veying roller and its axles.If the roller is worn
out, replace.
3
DP drive motor Check whether the DP drive
motor is fluctuated in rotation.
If the DP motor is fluctuated in rotation, apply
grease with the drive gear. If no improvement
is observed, replace the motor.

Utax P-4035 MFP Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	600 x 600 DPI
Time to first page (black, normal)	9 s
Print speed (black, normal quality, A4/US Letter)	40 ppm
Duplex print speed (black, normal quality, A4/US Letter)	20 ppm
Copier resize	25 - 400 %
Maximum number of copies	999 copies
Copy speed (black, normal quality, A4)	40 cpm
Scan to	E-mail, File, Image, USB
Grayscale levels	256
Image formats supported	JPG, TIF
Document formats supported	PDF, XPS
Faxing	Mono faxing
Fax memory	8 MB
Modem speed	33.6 Kbit/s
Fax coding methods	JBIG, MH, MMR (Fax coding method), MR
Fax resolution (black)	200 x 100 DPI
Fax transmission speed	3 sec/page
Digital sender	-
Printing colors	Black
Maximum duty cycle	- pages per month
Total input capacity	500 sheets
Total output capacity	250 sheets
Duplex media weight	60 - 120 g/m²
Paper tray media types	Envelopes
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Product color	Black, Grey
Market positioning	Business
Wi-Fi	No
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Mobile printing technologies	Apple AirPrint
Standard interfaces	Ethernet, USB 2.0
Memory slots	1
Internal memory	512 MB
Compatible memory cards	SD
Sound power level (standby)	53 dB
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Power consumption (standby)	54.7 W
Power consumption (average operating)	680 W

Weight and Dimensions

Depth	455 mm
Width	475 mm
Height	575 mm
Weight	21500 g
