Utax P-4035 MFP Service Manual

2NM/2NX/2NY/2NZ/2P0/2P6-1
1-3-58
U425 Set Target
Description
Enters the lab values that is indicated on the back of the chart (P/N: 302NM94340) used for
adjustment.
Purpose
Performs data input in order to correct for differences in originals during automatic adjustment.
Method
1. Press the start key.
2. Select the item to be set.
Display Description
Table Setting the value of the table adjustment.
DP Setting the value of DP adjustment.
Method: Table
1. Press the start key.
2. Select the item to be set.
Display Description
White Setting the white patch for the original for adjustment
Black Setting the black patch for the original for adjustment
Gray1 Setting the Gray1 patch for the original for adjustment
Gray2 Setting the Gray2 patch for the original for adjustment
Gray3 Setting the Gray3 patch for the original for adjustment
C Setting the cyan patch for the original for adjustment
M Setting the magenta patch for the original for adjustment
Y Setting the yellow patch for the original for adjustment
R Setting the red patch for the original for adjustment
G Setting the green patch for the original for adjustment
B Setting the blue patch for the original for adjustment
Adjust Original Setting the main and auxiliary scanning directions
3. Select the item to be set.
Display Description Setting range Initial setting
L Setting the L value 0.0 to 100.0 93.6/10.6/76.2/25.2/51.3
72.6/48.1/86.2/46.7/67.8/38.8
a Setting the a value -200.0 to 200.0 0.9/-0.2/-0.2/-0.2/-0.3
-32.8/69.9/-18.6/54.2/-51.3/25.3
b Setting the b value -200.0 to 200.0 -0.4/-0.7/1.2/-0.2/0.3
-11.5/-6.1/81.7/38.6/48.9/-22.8
4. Enters the value that is indicated on the face of the chart using the cursor right/left keys or
numeric keys.
5. Press the start key. The value is set.

Utax P-4035 MFP Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	600 x 600 DPI
Time to first page (black, normal)	9 s
Print speed (black, normal quality, A4/US Letter)	40 ppm
Duplex print speed (black, normal quality, A4/US Letter)	20 ppm
Copier resize	25 - 400 %
Maximum number of copies	999 copies
Copy speed (black, normal quality, A4)	40 cpm
Scan to	E-mail, File, Image, USB
Grayscale levels	256
Image formats supported	JPG, TIF
Document formats supported	PDF, XPS
Faxing	Mono faxing
Fax memory	8 MB
Modem speed	33.6 Kbit/s
Fax coding methods	JBIG, MH, MMR (Fax coding method), MR
Fax resolution (black)	200 x 100 DPI
Fax transmission speed	3 sec/page
Digital sender	-
Printing colors	Black
Maximum duty cycle	- pages per month
Total input capacity	500 sheets
Total output capacity	250 sheets
Duplex media weight	60 - 120 g/m²
Paper tray media types	Envelopes
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Product color	Black, Grey
Market positioning	Business
Wi-Fi	No
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Mobile printing technologies	Apple AirPrint
Standard interfaces	Ethernet, USB 2.0
Memory slots	1
Internal memory	512 MB
Compatible memory cards	SD
Sound power level (standby)	53 dB
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Power consumption (standby)	54.7 W
Power consumption (average operating)	680 W

Weight and Dimensions

Depth	455 mm
Width	475 mm
Height	575 mm
Weight	21500 g
