Utax P-4035 MFP Service Manual

2NM/2NX/2NY/2NZ/2P0/2P6
1-3-61
U520 Set TDRS
Description
Perform TDRS settings and information views.
Purpose
Perform TDRS settings and information views.
Method
1. Press the start key.
2. Select the item.
Display Description
Registration Transition to the TDRS Manager registering dialog
Information Transition to the Device Agent description dialog
On/Off Config Transition to the TDRS features dialog
Setting: [Registration]
Select the item.
Display Description
TDRS User Registering process using user and password
Access Code Registering process using an Access Code
Setting: [Access Code]
Select the item.
Display Description
Regist Performing registration to TDRS Manager
TDRS Server TDRS Server URL
TDRS User TDRS Username
Access Code TDRS Access Code
Proxy Server TDRS Proxy Server URL
Proxy Port TDRS Proxy Port Number
Proxy User TDRS Proxy Username
Text TDRS Description
* : The status of Online or Offline will be indicated at the right bottom depending on connection
with TDRS Manager.
The Regist button is inoperative if the USB is not installed.
A normal completion will be indicated by Complete in the status of the item that was per-
formed.
An occurrence of an error is indicated by an error number in the status of the item that was
performed.
If [User/Processing Registration using a Password] is selected in the previous dialog, the
TDRS User will be indicated.
If [Processing Registration using an Access Code] is selected, the Access Code will be
indicated.

Utax P-4035 MFP Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	600 x 600 DPI
Time to first page (black, normal)	9 s
Print speed (black, normal quality, A4/US Letter)	40 ppm
Duplex print speed (black, normal quality, A4/US Letter)	20 ppm
Copier resize	25 - 400 %
Maximum number of copies	999 copies
Copy speed (black, normal quality, A4)	40 cpm
Scan to	E-mail, File, Image, USB
Grayscale levels	256
Image formats supported	JPG, TIF
Document formats supported	PDF, XPS
Faxing	Mono faxing
Fax memory	8 MB
Modem speed	33.6 Kbit/s
Fax coding methods	JBIG, MH, MMR (Fax coding method), MR
Fax resolution (black)	200 x 100 DPI
Fax transmission speed	3 sec/page
Digital sender	-
Printing colors	Black
Maximum duty cycle	- pages per month
Total input capacity	500 sheets
Total output capacity	250 sheets
Duplex media weight	60 - 120 g/m²
Paper tray media types	Envelopes
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Product color	Black, Grey
Market positioning	Business
Wi-Fi	No
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Mobile printing technologies	Apple AirPrint
Standard interfaces	Ethernet, USB 2.0
Memory slots	1
Internal memory	512 MB
Compatible memory cards	SD
Sound power level (standby)	53 dB
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Power consumption (standby)	54.7 W
Power consumption (average operating)	680 W

Weight and Dimensions

Depth	455 mm
Width	475 mm
Height	575 mm
Weight	21500 g
