Utax P-4035 MFP Service Manual

2NM/2NX/2NY/2NZ/2P0/2P6
1-3-74
U630 Comm Ctrl 1
Description
Makes settings for fax transmission regarding the communication.
Purpose
The event of a request for user.
Reduce transmission time and the reception of accuracy when using poor quality line.
Improve the accuracy of communication at international communication.
Method
1. Press the start key.
2. Select the item to be set.
Display Description
TX Speed Sets the communication starting speed.
RX Speed Sets the reception speed.
TX Echo Sets the waiting period to prevent echo problems at the sender.
RX Echo Sets the waiting period to prevent echo problems at the receiver.
Setting the communication starting speed
Sets the initial communication speed when starting transmission. When the destination unit has
V.34 capability, V.34 is selected for transmission, regardless of this setting.
1. Select the setting.
Display Description
14400bps/V17 V.17, 14400 bps
9600bps/V29 V.17, 9600 bps
4800bps/V27ter V.27ter, 4800 bps
2400bps/V27ter V.27ter, 2400 bps
* : Initial setting: 14400bps/V17
2. Press the start key. The setting is set.
Setting the reception speed
Sets the reception speed that the sender is informed of using the DIS or NSF signal. When the
destination unit has V.34 capability, V.34 is selected, regardless of the setting.
1. Select the setting.
Display Description
14400bps V.17, V.33, V.29, V.27ter
9600bps V.29, V.27ter
4800bps V.27ter
2400bps V.27ter (fallback only)
* : Initial setting: 14400bps
2. Press the start key. The setting is set.

Utax P-4035 MFP Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	600 x 600 DPI
Time to first page (black, normal)	9 s
Print speed (black, normal quality, A4/US Letter)	40 ppm
Duplex print speed (black, normal quality, A4/US Letter)	20 ppm
Copier resize	25 - 400 %
Maximum number of copies	999 copies
Copy speed (black, normal quality, A4)	40 cpm
Scan to	E-mail, File, Image, USB
Grayscale levels	256
Image formats supported	JPG, TIF
Document formats supported	PDF, XPS
Faxing	Mono faxing
Fax memory	8 MB
Modem speed	33.6 Kbit/s
Fax coding methods	JBIG, MH, MMR (Fax coding method), MR
Fax resolution (black)	200 x 100 DPI
Fax transmission speed	3 sec/page
Digital sender	-
Printing colors	Black
Maximum duty cycle	- pages per month
Total input capacity	500 sheets
Total output capacity	250 sheets
Duplex media weight	60 - 120 g/m²
Paper tray media types	Envelopes
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Product color	Black, Grey
Market positioning	Business
Wi-Fi	No
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Mobile printing technologies	Apple AirPrint
Standard interfaces	Ethernet, USB 2.0
Memory slots	1
Internal memory	512 MB
Compatible memory cards	SD
Sound power level (standby)	53 dB
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Power consumption (standby)	54.7 W
Power consumption (average operating)	680 W

Weight and Dimensions

Depth	455 mm
Width	475 mm
Height	575 mm
Weight	21500 g
