2NM/2NX/2NY/2NZ/2P0/2P6
1-3-78
U632 Comm Ctrl 3
Description
Makes settings for fax transmission regarding the communication.
Purpose
Reduction of error communication when a low quality circuit is used.
When changing a FAX/TEL automatic change.
Method
1. Press the start key.
2. Select the item to be set.
Display Description
DIS 4Byte Sets the DIS signal to 4 bytes.
Num OF CNG(F/T) Sets the CNG detection times in the fax/telephone auto select mode.
Setting: DIS 4 byte
Sets if bit 33 and later bits of the DIS/DTC signal are sent.
1. Select the setting.
Display Description
On Bit 33 and later bits of the DIS/DTC signal are not sent.
Off Bit 33 and later bits of the DIS/DTC signal are sent.
* : Initial setting: Off
2. Press the start key. The setting is set.
Setting: Num CNG detection times in the fax/telephone auto select mode
Sets the CNG detection times in the fax/telephone auto select mode.
1. Select the setting.
Display Description
1Time Detects CNG once.
2Time Detects CNG twice.
* : Initial setting: 1times
2. Press the start key. The setting is set.
Completion
Press the stop key. The screen for selecting a maintenance item No. is displayed.
