Utax P-4035 MFP Service Manual

2NM/2NX/2NY/2NZ/2P0/2P6
1-3-93
No. bit Description
0 2400bps/V34
41 3 FSK detection in V.8
42 4 4800 bps when low-speed setting is active
2 FIF length in transmission of more than 4 times of DIS/DTC signal
<Communication time setting>
No. bit Description
53 76543210 T3 timeout setting
54 76543210 T4 timeout setting (automatic equipment)
55 76543210 T5 timeout setting
60 76543210 Time before transmission of CNG (1100 Hz) signal
63 76543210 T0 timeout setting (manual equipment)
64 7 Phase C timeout in ECM reception
66 76543210 Timeout 1 in countermeasures against echo
68 76543210 Timeout for FSK detection start in V.8
<Modem setting>
No. bit Description
89 76543 RX gain adjust
<NCU setting>
No. bit Description
121 7654 Dial tone/busy tone detection pattern
122 7654 Busy tone detection pattern
1 Busy tone detection in automatic FAX/TEL switching
125 76543210 Access code registration for connection to PSTN
126 7654 FAX/TEL automatic switching ringback tone ON/OFF cycle
<Calling time setting>
No. bit Description
133 76543210 DTMF signal transmission time
134 76543210 DTMF signal pause time
141 76543210 Ringer detection cycle (minimum)
142 76543210 Ringer detection cycle (maximum)
143 76543210 Ringer ON time detection
144 76543210 Ringer OFF time detection
145 76543210 Ringer OFF non-detection time
147 76543210 Dial tone detection time (continuous tone)

Utax P-4035 MFP Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	600 x 600 DPI
Time to first page (black, normal)	9 s
Print speed (black, normal quality, A4/US Letter)	40 ppm
Duplex print speed (black, normal quality, A4/US Letter)	20 ppm
Copier resize	25 - 400 %
Maximum number of copies	999 copies
Copy speed (black, normal quality, A4)	40 cpm
Scan to	E-mail, File, Image, USB
Grayscale levels	256
Image formats supported	JPG, TIF
Document formats supported	PDF, XPS
Faxing	Mono faxing
Fax memory	8 MB
Modem speed	33.6 Kbit/s
Fax coding methods	JBIG, MH, MMR (Fax coding method), MR
Fax resolution (black)	200 x 100 DPI
Fax transmission speed	3 sec/page
Digital sender	-
Printing colors	Black
Maximum duty cycle	- pages per month
Total input capacity	500 sheets
Total output capacity	250 sheets
Duplex media weight	60 - 120 g/m²
Paper tray media types	Envelopes
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Product color	Black, Grey
Market positioning	Business
Wi-Fi	No
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Mobile printing technologies	Apple AirPrint
Standard interfaces	Ethernet, USB 2.0
Memory slots	1
Internal memory	512 MB
Compatible memory cards	SD
Sound power level (standby)	53 dB
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Power consumption (standby)	54.7 W
Power consumption (average operating)	680 W

Weight and Dimensions

Depth	455 mm
Width	475 mm
Height	575 mm
Weight	21500 g
