Utax P-4035 MFP Service Manual

2NM/2NX/2NY/2NZ/2P0/2P6
1-4-103
(20)
A message indicat-
ing cover open is
displayed when the
rear cover is
closed.
(50/60 ppm model
only)
1. Defective connector
cable or poor con-
tact in the connector.
Reinsert the connector. Also check for continuity within the
connector cable. If none, replace the cable.
Rear cover switch and connect left PWB (YC10)
Connect left PWB and control PWB (YC2)
2. Defective rear cover
switch.
Check and replace if necessary.
3. Defective connect
left PWB.
Replace the connect left PWB (see page 2-2-36).
4. Defective PWB. Replace the control PWB and check for correct operation
(see page 2-2-12).
(21)
DP paper feed
motor does not
operate.
1. Defective connector
cable or poor con-
tact in the connector.
Reinsert the connector. Also check for continuity within the
connector cable. If none, remedy or replace the cable.
DP paper feed motor and control PWB (YC1001)
2. Defective drive trans-
mission system.
Check if the rollers and gears rotate smoothly. If not,
grease the bushes and gears. Check for broken gears and
replace if any.
3. Defective motor. Replace the DP paper feed motor.
4. Defective PWB. Replace the control PWB and check for correct operation
(see page 2-2-12).
(22)
DP paper convey-
ing motor does not
operate.
1. Defective connector
cable or poor con-
tact in the connector.
Reinsert the connector. Also check for continuity within the
connector cable. If none, remedy or replace the cable.
DP conveying motor and control PWB (YC1001)
2. Defective drive trans-
mission system.
Check if the rollers and gears rotate smoothly. If not,
grease the bushes and gears. Check for broken gears and
replace if any.
3. Defective motor. Replace the DP conveying motor.
4. Defective PWB. Replace the control PWB and check for correct operation
(see page 2-2-12).
(23)
DP switchback
motor does not
operate.
1. Defective connector
cable or poor con-
tact in the connector.
Reinsert the connector. Also check for continuity within the
connector cable. If none, remedy or replace the cable.
DP switchback motor and control PWB (YC1001)
2. Defective motor. Replace the DP switchback motor.
3. Defective PWB. Replace the control PWB and check for correct operation
(see page 2-2-12).
(24)
An original jams
when the main
power switch is
turned on.
1. A piece of paper torn
from an original is
caught around the
DP timing sensor,
DP ragistration sen-
sor or DP switchback
sensor.
Check visually and remove it, if any.
2. Defective DP timing
sensor.
Replace the DP timing sensor, DP ragistration sensor or
DP switchback sensor.
3. Defective PWB. Replace the control PWB and check for correct operation
(see page 2-2-12).
Problem Causes Check procedures/corrective measures

Utax P-4035 MFP Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	600 x 600 DPI
Time to first page (black, normal)	9 s
Print speed (black, normal quality, A4/US Letter)	40 ppm
Duplex print speed (black, normal quality, A4/US Letter)	20 ppm
Copier resize	25 - 400 %
Maximum number of copies	999 copies
Copy speed (black, normal quality, A4)	40 cpm
Scan to	E-mail, File, Image, USB
Grayscale levels	256
Image formats supported	JPG, TIF
Document formats supported	PDF, XPS
Faxing	Mono faxing
Fax memory	8 MB
Modem speed	33.6 Kbit/s
Fax coding methods	JBIG, MH, MMR (Fax coding method), MR
Fax resolution (black)	200 x 100 DPI
Fax transmission speed	3 sec/page
Digital sender	-
Printing colors	Black
Maximum duty cycle	- pages per month
Total input capacity	500 sheets
Total output capacity	250 sheets
Duplex media weight	60 - 120 g/m²
Paper tray media types	Envelopes
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Product color	Black, Grey
Market positioning	Business
Wi-Fi	No
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Mobile printing technologies	Apple AirPrint
Standard interfaces	Ethernet, USB 2.0
Memory slots	1
Internal memory	512 MB
Compatible memory cards	SD
Sound power level (standby)	53 dB
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Power consumption (standby)	54.7 W
Power consumption (average operating)	680 W

Weight and Dimensions

Depth	455 mm
Width	475 mm
Height	575 mm
Weight	21500 g
