Utax P-4035 MFP Service Manual

2NM/2NX/2NY/2NZ/2P0/2P6-1
2-1-6
1. MP paper sensor (MPPS) ..................... Detects the presence of paper on the MP tray.
2. Lift sensor (LS) *2 ................................. Detects the top limit of the bottom plate.
3. Registration sensor 2 (RS2) *2 ............. Controls the secondary paper feed start timing.
4. Duplex sensor 1 (DUS1) *2................... Detects a paper jam in the duplex section.
5. Eject sensor (ES) .................................. Detects a paper misfeed in the fuser or eject section.
6. Home position sensor (HPS) ................ Detects the ISU in the home position.
7. Toner sensor (TS) ................................. Detects the amount of toner remaining in the toner container.
8. Waste toner sensor (WTS).................... Detects when the waste toner box is full.
9. Fuser thermistor1 (FTH1) ..................... Detects the heat roller temperature (Edge).
10. Fuser thermistor2 (FTH2) ..................... Detects the heat roller temperature (Center).
11. Power source switch (PSSW) ............... Change ON/OFF the power supply of a control PWB, an opera-
tion PWB, etc.
12. Inter lock switch (ILSW) ........................ Detects the opening and closing of the top cover.
13. Rear cover switch (RCSW) *2............... Detects the opening and closing of the rear cover.
Shuts off 24 V DC power line when the right cover is opened.
14. Paper full sensor (PFS)......................... Detects the paper full in the main tray (Facedown).
15. Envelope sensor (ENVS) ...................... Detects the change state of pressure in fuser unit.
16. Cassette size switch (CSSW) ............... Detects the paper size dial setting of the paper setting dial.
17. DP original sensor (DPOS) ................... Detects the presence of an original.
18. DP registration sensor (DPRS) ............. Detects the original conveying timing.
19. DP timing sensor (DPTS)...................... Detects the original scanning timing.
20. DP switchback sensor (DPSBS) ........... Detects the position of the shift guide.
21. DP open/close sensor (DPOCS)........... Detects the opening/closing of the DP.
List of correspondences of switch and sensor names
No. Name used in service manual Name used in parts list Part.No.
1 MP paper sensor (MPPS) SENSOR OPT. 303M894260
2 Lift sensor (LS) *2 SENSOR OPT. 303M894260
3 Registration sensor 2 (RS2) *2 SENSOR OPT. -
4 Duplex sensor1 (DUS1) *2 SENSOR OPT. 303M894260
5
Eject sensor (ES)
SENSOR OPT.
(FK-3100(U)) *1
(FK-3100(E)) *1
(FK-3130(U)) *2
(FK-3130(E)) *2
-
(302MS93094)
(302MS93074)
(302LV93132)
(302LV93112)
6 Home position sensor (HPS) SENSOR OPT. 303M894260
7
Toner sensor (TS)
P.W.BOARD ASSY TONER SENSOR
(DV-3100)
-
(302LV93080)
8
Waste toner sensor (WTS)
PARTS TONER FULL DETECT
ASSY SP
302LV94120
9
Fuser thermistor1 (FTH1)
THERMISTOR FUSER
(FK-3100(U)) *1
(FK-3100(E)) *1
(FK-3130(U)) *2
(FK-3130(E)) *2
-
(302MS93094)
(302MS93074)
(302LV93132)
(302LV93112)

Utax P-4035 MFP Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	600 x 600 DPI
Time to first page (black, normal)	9 s
Print speed (black, normal quality, A4/US Letter)	40 ppm
Duplex print speed (black, normal quality, A4/US Letter)	20 ppm
Copier resize	25 - 400 %
Maximum number of copies	999 copies
Copy speed (black, normal quality, A4)	40 cpm
Scan to	E-mail, File, Image, USB
Grayscale levels	256
Image formats supported	JPG, TIF
Document formats supported	PDF, XPS
Faxing	Mono faxing
Fax memory	8 MB
Modem speed	33.6 Kbit/s
Fax coding methods	JBIG, MH, MMR (Fax coding method), MR
Fax resolution (black)	200 x 100 DPI
Fax transmission speed	3 sec/page
Digital sender	-
Printing colors	Black
Maximum duty cycle	- pages per month
Total input capacity	500 sheets
Total output capacity	250 sheets
Duplex media weight	60 - 120 g/m²
Paper tray media types	Envelopes
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Product color	Black, Grey
Market positioning	Business
Wi-Fi	No
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Mobile printing technologies	Apple AirPrint
Standard interfaces	Ethernet, USB 2.0
Memory slots	1
Internal memory	512 MB
Compatible memory cards	SD
Sound power level (standby)	53 dB
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Power consumption (standby)	54.7 W
Power consumption (average operating)	680 W

Weight and Dimensions

Depth	455 mm
Width	475 mm
Height	575 mm
Weight	21500 g
