Utax P-4035 MFP Service Manual

2NM/2NX/2NY/2NZ/2P0/2P6-1
2-1-9
1. Main motor (MM) *1 .............................. Drives the paper feed section and conveying section.
2. Main motor (MM) *2 .............................. Drives the paper feed section and conveying section.
3. Drum motor (DRM) *2 ........................... Drives the drum unit and transfer roller.
4. Lift motor (LM)*2 ................................... Operates the bottom plate in the cassette.
5. Image scanner motor (ISUM)................ Drives the ISU.
6. Polygon motor (PM) .............................. Drives the polygon mirror.
7. Toner motor (TM) .................................. Replenishes toner to the developing unit.
8. Eject motor (EM) ................................... Drives the duplex section.
9. Envelope motor (ENVM) *2................... Drives the change mechanism of fixing pressure in fuser unit.
10. Developer fan motor (DEVFM) ............. Cools the developer section.
11. LSU fan motor (LSUFM) ....................... Cools the LSU unit.
12. Power source fan motor (PSFM) .......... Cools the power source PWB.
13. DP paper feed motor (DPPFM)............. Drives the original feed section.
14. DP paper conveying motor (DPCM) ..... Drives the original conveying section.
15. DP switchback motor (DPSBM) ............ Drives the switchback roller.
List of correspondences of motor names
No. Name used in service manual Name used in parts list Part.No.
1 Main motor (MM) *1 PARTS MOTOR-BL W30 SP 302K394201
2 Main motor (MM) *2 PARTS MOTOR-BL W30 SP 302K394201
3 Drum motor (DRM) *2 PARTS MOTOR-BL W30 SP 302K394201
4 Lift motor (LM) *2 PARTS DC MOTOR ASSY SP 302LV94230
5 Image scanner motor (ISUM) MOTOR ISU 302H994270
6 Polygon motor (PM)
MOTOR POLYGON
(LK-3200)
(LK-3230) *7
-
(302NZ93010)
(302P693010)
7 Toner motor (TM)
TONER MOTOR ASSY
(DK-3100(U)) *1
(DK-3100(E)) *1
(DK-3100(AO)) *1
(DK-3130(U)) *2
(DK-3130(E)) *2
(DK-3130(AO)) *2
-
(302MS93042)
(302MS93022)
(302MS93052)
(302LV93062)
(302LV93042)
(302LV93072)
8 Eject motor (EM) MOTOR EJECT 302F944131
9 Envelope motor (ENVM) PARTS DC MOTOR ASSY SP 302LV94230
10 Developer fan motor (DEVFM) FAN MOTOR 302HN44010
11 LSU fan motor (LSUFM) FAN LSU 60-25 302GR44080
12 Power source fan motor (PSFM) PARTS,FAN COOLING CONVEYING SP 302FZ94420
13 DP paper feed motor (DPPFM)
MOTOR PAPER FEED
(PARTS DRIVE ASSY A SP)
-
(302NM94230)
14 DP paper conveying motor (DPCM)
MOTOR-HB PAPER FEED
(PARTS DRIVE ASSY A SP)
-
(302NM94230)

Utax P-4035 MFP Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	600 x 600 DPI
Time to first page (black, normal)	9 s
Print speed (black, normal quality, A4/US Letter)	40 ppm
Duplex print speed (black, normal quality, A4/US Letter)	20 ppm
Copier resize	25 - 400 %
Maximum number of copies	999 copies
Copy speed (black, normal quality, A4)	40 cpm
Scan to	E-mail, File, Image, USB
Grayscale levels	256
Image formats supported	JPG, TIF
Document formats supported	PDF, XPS
Faxing	Mono faxing
Fax memory	8 MB
Modem speed	33.6 Kbit/s
Fax coding methods	JBIG, MH, MMR (Fax coding method), MR
Fax resolution (black)	200 x 100 DPI
Fax transmission speed	3 sec/page
Digital sender	-
Printing colors	Black
Maximum duty cycle	- pages per month
Total input capacity	500 sheets
Total output capacity	250 sheets
Duplex media weight	60 - 120 g/m²
Paper tray media types	Envelopes
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Product color	Black, Grey
Market positioning	Business
Wi-Fi	No
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Mobile printing technologies	Apple AirPrint
Standard interfaces	Ethernet, USB 2.0
Memory slots	1
Internal memory	512 MB
Compatible memory cards	SD
Sound power level (standby)	53 dB
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Power consumption (standby)	54.7 W
Power consumption (average operating)	680 W

Weight and Dimensions

Depth	455 mm
Width	475 mm
Height	575 mm
Weight	21500 g
