Utax P-4035 MFP Service Manual

2NM/2NX/2NY/2NZ/2P0/2P6-1
2-1-12
1. Paper feed clutch (PFCL) ..................... Primary paper feed from cassette.
2. Registration clutch (RCL)...................... Controls the secondary paper feed.
3. Duplex clutch (DUCL) *2....................... Controls the drive of the duplex feed roller.
4. Middle clutch (MIDCL) *2 ...................... Controls the paper conveying at the conveying section.
5. Developer clutch (DEVCL).................... Controls the drive of the developer.
6. MP solenoid (MPSOL) .......................... Controls the MP bottom plate.
7. Faceup solenoid (FUSOL) *2................ Operates the feedshift guide.
8. Cleaning lamp (CL) ............................... Eliminates the residual electrostatic charge on the drum.
9. Fuser heater 1 (FUH1).......................... Heats the heat roller.
10. Fuser heater 2 (FUH2) *2 ..................... Heats the heat roller.
11. Fuser thermostat 1 (FUTS1) ................. Prevents overheating of the heat roller.
12. Fuser thermostat 2 (FUTS2) *2............. Prevents overheating of the heat roller.
List of correspondences of other names
*1: 40 ppm model only, *2: 50/60 ppm model only
No. Name used in service manual Name used in parts list Part.No.
1 Paper feed clutch (PFCL)
PARTS CLUTCH 20-2W Z35R
(RARTS DRIVE FEED ASSY SP)
-
(302LV94251)
2 Registration clutch (RCL)
CLUTCH 50 Z35R 302KV44041
3 Duplex clutch (DUCL) *2
PARTS CLUTCH 20-2W Z35R -
4 Middle clutch (MIDCL) *2
PARTS CLUTCH 20-2W Z35R
(RARTS DRIVE FEED ASSY SP)
-
(302LV94251)
5 Developer clutch (DEVCL)
PARTS CLUTCH 20-2W Z35R 302VL94161
6 MP solenoid (MPSOL)
SOLENOID MPF
(RARTS DRIVE FEED ASSY SP)
-
(302LV94251)
7 Faceup solenoid (FUSOL) *2 SOLENOID EXIT -
8 Cleaning lamp (CL)
P.W.BOARD ASSY ERASER
(DK-3100(U)) *1
(DK-3100(E)) *1
(DK-3100(AO)) *1
(DK-3130(U)) *2
(DK-3130(E)) *2
(DK-3130(AO)) *2
-
(302MS93042)
(302MS93022)
(302MS93052)
(302LV93062)
(302LV93042)
(302LV93072)
9 Fuser heater 1 (FH1) HEATER LAMP 120 *1
(FK-3100(U)) *1
HEATER LAMP 240 *1
(FK-3100(E)) *1
HEATER LAMP 120 *2
(FK-3130(U)) *2
HEATER LAMP 240 *2
(FK-3130(E)) *2
-
(302MS93094)
302L244030
(302MS93074)
302LV44020
(302LV93132)
302LV44031
(302LV93112)
10 Fuser heater 2 (FH2) *2
11 Fuser thermostat 1 (FTS1) THERMAL-CUTOUT 202 FUSER
(FK-3100(U)) *1
(FK-3100(E)) *1
(FK-3130(U)) *2
(FK-3130(E)) *2
-
(302MS93094)
(302MS93074)
(302LV93132)
(302LV93112)
12 Fuser thermostat 2 (FTS2) *2

Utax P-4035 MFP Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	600 x 600 DPI
Time to first page (black, normal)	9 s
Print speed (black, normal quality, A4/US Letter)	40 ppm
Duplex print speed (black, normal quality, A4/US Letter)	20 ppm
Copier resize	25 - 400 %
Maximum number of copies	999 copies
Copy speed (black, normal quality, A4)	40 cpm
Scan to	E-mail, File, Image, USB
Grayscale levels	256
Image formats supported	JPG, TIF
Document formats supported	PDF, XPS
Faxing	Mono faxing
Fax memory	8 MB
Modem speed	33.6 Kbit/s
Fax coding methods	JBIG, MH, MMR (Fax coding method), MR
Fax resolution (black)	200 x 100 DPI
Fax transmission speed	3 sec/page
Digital sender	-
Printing colors	Black
Maximum duty cycle	- pages per month
Total input capacity	500 sheets
Total output capacity	250 sheets
Duplex media weight	60 - 120 g/m²
Paper tray media types	Envelopes
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Product color	Black, Grey
Market positioning	Business
Wi-Fi	No
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Mobile printing technologies	Apple AirPrint
Standard interfaces	Ethernet, USB 2.0
Memory slots	1
Internal memory	512 MB
Compatible memory cards	SD
Sound power level (standby)	53 dB
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Power consumption (standby)	54.7 W
Power consumption (average operating)	680 W

Weight and Dimensions

Depth	455 mm
Width	475 mm
Height	575 mm
Weight	21500 g
