Utax P-4035 MFP Service Manual

2NM/2NX/2NY/2NZ/2P0/2P6
2-2-9
YC1000
25 CCDRS- O LVDS CCD reset signal
Connected to
the CCD
PWB
26 GND - - Ground
27 N.C. - - Not used
28 +3.3V3 E1 O 3.3 V DC 3.3 V DC power output
29 HP SWN I 0/3.3 V DC HPS: On/Off
30 GND - - Ground
31 M LED C I 0 to 2 V DC LED CATHODE
32 M LED A O 3 V DC LED ANODE
YC1001
1 CONNMOTB2 O 0/24 V DC(pulse) DPCM drive control signal
Connected to
the convey-
ing motor, DP
switchback
motor, DP
paper feed
motor
2 CONNMOTB1 O 0/24 V DC(pulse) DPCM drive control signal
3 CONNMOTA2 O 0/24 V DC(pulse) DPCM drive control signal
4 CONNMOTA1 O 0/24 V DC(pulse) DPCM drive control signal
5 JNCMOTB2 O 0/24 V DC(pulse) DPSBM drive control signal
6 JNCMOTA2 O 0/24 V DC(pulse) DPSBM drive control signal
7 JNCMOTB1 O 0/24 V DC(pulse) DPSBM drive control signal
8 JNCMOTA1 O 0/24 V DC(pulse) DPSBM drive control signal
9 FEEDMOTB2 O 0/24 V DC(pulse) DPPFM drive control signal
10 FEEDMOTB1 O 0/24 V DC(pulse) DPPFM drive control signal
11 FEEDMOTA2 O 0/24 V DC(pulse) DPPFM drive control signal
12 FEEDMOTA1 O 0/24 V DC(pulse) DPPFM drive control signal
YC1002
1 SCMOTB2 O 0/24 V DC(pulse) ISUM drive control signal
Connected to
the image
scanner
motor
2 SCMOTA1 O 0/24 V DC(pulse) ISUM drive control signal
3 SCMOTB1 O 0/24 V DC(pulse) ISUM drive control signal
4 SCMOTA2 O 0/24 V DC(pulse) ISUM drive control signal
YC1003
1 +3.3V3S O 3.3 V DC 3.3 V DC power output
Connected to
the DP origi-
nal sensor,
theDP regist
sensor, DP
open/close
sensor, DP
switchback
sensor, DP
timing sensor
2 GND - - Ground
3 SET_SW I 0/3.3 V DC DPOS: On/Off
4 +3.3V3S O 3.3 V DC 3.3 V DC power output
5 GND - - Ground
6 REGIST_SW I 0/3.3 V DC DPRS: On/Off
7 +3.3V3S O 3.3 V DC 3.3 V DC power output
8 GND - - Ground
9 DP_OPEN_S
W
I 0/3.3 V DC DPOCS: On/Off
10 +3.3V3S O 3.3 V DC 3.3 V DC power output
Connector Pin Signal I/O Voltage Description

Utax P-4035 MFP Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	600 x 600 DPI
Time to first page (black, normal)	9 s
Print speed (black, normal quality, A4/US Letter)	40 ppm
Duplex print speed (black, normal quality, A4/US Letter)	20 ppm
Copier resize	25 - 400 %
Maximum number of copies	999 copies
Copy speed (black, normal quality, A4)	40 cpm
Scan to	E-mail, File, Image, USB
Grayscale levels	256
Image formats supported	JPG, TIF
Document formats supported	PDF, XPS
Faxing	Mono faxing
Fax memory	8 MB
Modem speed	33.6 Kbit/s
Fax coding methods	JBIG, MH, MMR (Fax coding method), MR
Fax resolution (black)	200 x 100 DPI
Fax transmission speed	3 sec/page
Digital sender	-
Printing colors	Black
Maximum duty cycle	- pages per month
Total input capacity	500 sheets
Total output capacity	250 sheets
Duplex media weight	60 - 120 g/m²
Paper tray media types	Envelopes
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Product color	Black, Grey
Market positioning	Business
Wi-Fi	No
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Mobile printing technologies	Apple AirPrint
Standard interfaces	Ethernet, USB 2.0
Memory slots	1
Internal memory	512 MB
Compatible memory cards	SD
Sound power level (standby)	53 dB
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Power consumption (standby)	54.7 W
Power consumption (average operating)	680 W

Weight and Dimensions

Depth	455 mm
Width	475 mm
Height	575 mm
Weight	21500 g
