Utax P-4035 MFP Service Manual

2NM/2NX/2NY/2NZ/2P0/2P6
2-2-11
*1: 50/60 ppm model only
*2: Basic model only
*3: HyPAS model only
YC2002 *2
1 GND - - Ground
Connected to
the opera-
tion panel
PWB
2- -- Not used
3INT_POWER
KEY_N
I 0/3.3 V DC Power key: On/Off
4 FPRST O 0/3.3 V DC Panel reset signal
5 AUDIO O Analog Voice output signal
6- -- Not used
7 PAN_TXD O 0/3.3 V DC Serial comunication data signal
8 PAN_RXD I 0/3.3 V DC Serial comunication data signal
9- -- Not used
10 - - - Not used
11 5.0V2_C O 5 V DC 5 V DC power output
12 - - - Not used
13 LCDCON O 0/3.3 V DC LCD control signal
14 3.3V1_C O 0/3.3 V DC 3.3 V DC power output
15 GND - - Ground
YC2003 *3
1 +5V0 PANEL O 5 V DC 5 V DC power output
Connected to
the opera-
tion panel
PWB
2 +5V0 PANEL O 5 V DC 5 V DC power output
3 GND - - Ground
4 GND - - Ground
Connector Pin Signal I/O Voltage Description

Utax P-4035 MFP Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	600 x 600 DPI
Time to first page (black, normal)	9 s
Print speed (black, normal quality, A4/US Letter)	40 ppm
Duplex print speed (black, normal quality, A4/US Letter)	20 ppm
Copier resize	25 - 400 %
Maximum number of copies	999 copies
Copy speed (black, normal quality, A4)	40 cpm
Scan to	E-mail, File, Image, USB
Grayscale levels	256
Image formats supported	JPG, TIF
Document formats supported	PDF, XPS
Faxing	Mono faxing
Fax memory	8 MB
Modem speed	33.6 Kbit/s
Fax coding methods	JBIG, MH, MMR (Fax coding method), MR
Fax resolution (black)	200 x 100 DPI
Fax transmission speed	3 sec/page
Digital sender	-
Printing colors	Black
Maximum duty cycle	- pages per month
Total input capacity	500 sheets
Total output capacity	250 sheets
Duplex media weight	60 - 120 g/m²
Paper tray media types	Envelopes
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Product color	Black, Grey
Market positioning	Business
Wi-Fi	No
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Mobile printing technologies	Apple AirPrint
Standard interfaces	Ethernet, USB 2.0
Memory slots	1
Internal memory	512 MB
Compatible memory cards	SD
Sound power level (standby)	53 dB
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Power consumption (standby)	54.7 W
Power consumption (average operating)	680 W

Weight and Dimensions

Depth	455 mm
Width	475 mm
Height	575 mm
Weight	21500 g
