NOTE:The following operations are required when replacing the main board.
1. Execute maintenance mode U004 to resolve machine number mismatch that appears after replacing
the main board.
* : When the machine number of control board does not match, C0180 will be displayed.
2. Adjust the scanner image.
(1)Input the value in the auto scanner adjustment chart by using the maintenance mode U425.
(2)Execute the maintenance mode U411 with the auto scanner adjustment chart.
(3)Execute [Halftone adjustment] from the system menu
3. Reactivate the license for optional products if any were installed.
(1)Reactivate ID CARD AUTHENTICATION KIT B).
(2)Register an ID card again by using the maintenance mode U222.
4. Import data if any was exported from the machine before replacing the main board by using the main-
tenance mode U917. (The export and import is also available via KM-Net Viewer)
5. Register the initial user settings and FAX settings from the system menu or command center.
6. Execute the maintenance mode as below if necessary.
No. Main machine related maintenance modes No. Fax related maintenance modes
U250 Checking/clearing the maintenance cycle U603 Setting user data 1
U251 Checking/clearing the maintenance counter U604 Setting user data 2
U253 Switching between double and single counts U610 Setting system 1
U260 Selecting the timing for copy counting U611 Setting system 2
U345 Setting the value for maintenance due indica-
tion
U612 Setting system 3
U402 Adjusting margins of image printing U625 Setting the transmission system 1
U403 Adjusting margins for scanning an original on
the contact glass
U695 FAX function customize
U404 Adjusting margins for scanning an original from
the DP
U425 Setting the target

Utax P-4035 MFP Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	600 x 600 DPI
Time to first page (black, normal)	9 s
Print speed (black, normal quality, A4/US Letter)	40 ppm
Duplex print speed (black, normal quality, A4/US Letter)	20 ppm
Copier resize	25 - 400 %
Maximum number of copies	999 copies
Copy speed (black, normal quality, A4)	40 cpm
Scan to	E-mail, File, Image, USB
Grayscale levels	256
Image formats supported	JPG, TIF
Document formats supported	PDF, XPS
Faxing	Mono faxing
Fax memory	8 MB
Modem speed	33.6 Kbit/s
Fax coding methods	JBIG, MH, MMR (Fax coding method), MR
Fax resolution (black)	200 x 100 DPI
Fax transmission speed	3 sec/page
Digital sender	-
Printing colors	Black
Maximum duty cycle	- pages per month
Total input capacity	500 sheets
Total output capacity	250 sheets
Duplex media weight	60 - 120 g/m²
Paper tray media types	Envelopes
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Product color	Black, Grey
Market positioning	Business
Wi-Fi	No
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Mobile printing technologies	Apple AirPrint
Standard interfaces	Ethernet, USB 2.0
Memory slots	1
Internal memory	512 MB
Compatible memory cards	SD
Sound power level (standby)	53 dB
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Power consumption (standby)	54.7 W
Power consumption (average operating)	680 W

Weight and Dimensions

Depth	455 mm
Width	475 mm
Height	575 mm
Weight	21500 g
