Utax P-4035 MFP Service Manual

2NM/2NX/2NY/2NZ/2P0/2P6
2-2-55
YC8
1 SCAN0 O 0/3.3 V DC (pulse) Scan signal 0
Connected to
the key-right
PWB
2 SCAN1 O 0/3.3 V DC (pulse) Scan signal 1
3 SCAN2 O 0/3.3 V DC (pulse) Scan signal 2
4 SCAN3 O 0/3.3 V DC (pulse) Scan signal 3
5 SCAN4 O 0/3.3 V DC (pulse) Scan signal 4
6 LEDRIGHT0 O 0/3.3 V DC (pulse) Operation panel LED display drive
signal 0
7 KEYRIGHT0 I 0/3.3 V DC (pulse) Operation panel key scan return signal 0
8 KEYRIGHT1 I 0/3.3 V DC (pulse) Operation panel key scan return signal 1
9 KEYRIGHT2 I 0/3.3 V DC (pulse) Operation panel key scan return signal 2
10 KEYRIGHT3 I 0/3.3 V DC (pulse) Operation panel key scan return signal 3
11 KEYRIGHT4 I 0/3.3 V DC (pulse) Operation panel key scan return signal 4
12 LEDRIGHT1 O 0/3.3 V DC (pulse) Operation panel LED display drive
signal 1
13 P LED O 0/3.3 V DC Processing LED control signal
14 M LED O 0/3.3 V DC Memory LED control signal
15 A LED O 0/3.3 V DC Attention LED control signal
16 INT_POWER
KEY_N
I 0/3.3 V DC Power key: On/Off
17 SUPEND_PO
WER
O 3.3V DC 3.3 V DC power input from MPWB
18 GND - - Ground
YC9
1 SPK+ O Analog Speaker sound signal (+)
Connected to
the speaker
2 SPK- O Analog Speaker sound signal (-)
YC17
1- -- Not used
Connected to
the control
PWB
2 +5V0 PANEL I 5 V DC 5 V DC power input
3 +5V0 PANEL I 5 V DC 5 V DC power input
4 GND - - Ground
5 GND - - Ground
6- -- Not used
YC18
1 X2 I/O Analog Touch panel control signal
Connected to
the touch
panel
2 Y2 I/O Analog Touch panel control signal
3 X1 I/O Analog Touch panel control signal
4 Y1 I/O Analog Touch panel control signal
YC21
1 LEDA_OR_5V O 0/20 V DC Backlight LED Anode
Connected to
the back light
2LEDC_OR_G
ND
O 0/5 V DC Backlight LED Cathode
Connector Pin Signal I/O Voltage Description

Utax P-4035 MFP Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	600 x 600 DPI
Time to first page (black, normal)	9 s
Print speed (black, normal quality, A4/US Letter)	40 ppm
Duplex print speed (black, normal quality, A4/US Letter)	20 ppm
Copier resize	25 - 400 %
Maximum number of copies	999 copies
Copy speed (black, normal quality, A4)	40 cpm
Scan to	E-mail, File, Image, USB
Grayscale levels	256
Image formats supported	JPG, TIF
Document formats supported	PDF, XPS
Faxing	Mono faxing
Fax memory	8 MB
Modem speed	33.6 Kbit/s
Fax coding methods	JBIG, MH, MMR (Fax coding method), MR
Fax resolution (black)	200 x 100 DPI
Fax transmission speed	3 sec/page
Digital sender	-
Printing colors	Black
Maximum duty cycle	- pages per month
Total input capacity	500 sheets
Total output capacity	250 sheets
Duplex media weight	60 - 120 g/m²
Paper tray media types	Envelopes
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Product color	Black, Grey
Market positioning	Business
Wi-Fi	No
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Mobile printing technologies	Apple AirPrint
Standard interfaces	Ethernet, USB 2.0
Memory slots	1
Internal memory	512 MB
Compatible memory cards	SD
Sound power level (standby)	53 dB
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Power consumption (standby)	54.7 W
Power consumption (average operating)	680 W

Weight and Dimensions

Depth	455 mm
Width	475 mm
Height	575 mm
Weight	21500 g
