2NM/2NX/2NY/2NZ/2P0/2P6
2-2-57
4. Remove four screws and the operation
panel PWB.
5. Check or replace the operation panel
PWB and refit all the removed parts.
Figure 2-2-70
Screw
Screw
Screw
Screw
Operation panel PWB
Operation panel
assembly
