2NM/2NX/2NY/2NZ/2P0/2P6-5
No. Content
Check procedure & check point
Remark (Common)
P-4030 MFP
P-4035 MFP
P-4030iMFP, P-4035iMFP
P-5035iMFP, P-6035iMFP
F33X
An error is detected at the
Scan management section
1) Check the wire and the connection of the connectors between the
control PWB and CCD, and check function.
2) Execute U021 (Init memory) and check function.
3) Replace the CCD PWB and check function.
4) Replace the control PWB and check function.
5) Retrieve the USBLOG and contact the Service Administrative
Division.
[Control PWB-CCD PWB interface]
Control PWB: YC1000
CCD PWB: YC1
[Control PWB-CCD PWB interface]
Control PWB: YC1000
CCD PWB: YC1
F34X
An error is detected at the
Panel management section
1) Check the wire and the connection of the connectors between the
operation panel PWB and the control PWB, and check function.(For
HyPAS model only)
2) Execute U021 (Init memory) and check function.
3) Replace the operation panel PWB and check function.(For HyPAS
model only)
4) Replace the control PWB and check function.
5) Retrieve the USBLOG and contact the Service Administrative
Division.
Error in the panel processing
(Timeout for waiting the
response from command, etc.)
1) at the left is unnecessary because the
F34X error is caused by the software.
As the hardware cause, it will be caused
by disconnecting the connector of the wire
between the control PWB and the
operation panel PWB.
F35X
An error is detected at the
Print control section
1) Execute U021 (Init memory) and check function.
2) Replace the control PWB and check function.
3) Retrieve the USBLOG and contact the Service Administrative
Division.
--
F37X
An error is detected at the
FAX management section
1) Execute U021 (Init memory) and check function.
2) Replace the control PWB and check function.
3) Retrieve the USBLOG and contact the Service Administrative
Division.
--
F38X
An error is detected at the
Authentication/permit
management section
1) Execute U021 (Init memory) and check function.
2) Replace the control PWB and check function.
3) Retrieve the USBLOG and contact the Service Administrative
Division.
--
F48X
An error is detected at the
Image edit process control
section
1) Execute U021 (Init memory) and check function.
2) Replace the control PWB and check function.
3) Retrieve the USBLOG and contact the Service Administrative
Division.
--
F4DX
An error is detected at the
Entity control section
1) Execute U021 (Init memory) and check function.
2) Replace the control PWB and check function.
3) Retrieve the USBLOG and contact the Service Administrative
Division.
--
F50X
An error is detected at the
FAX control section
1) Execute U021 (Init memory) and check function.
2) Replace the control PWB and check function.
3) Retrieve the USBLOG and contact the Service Administrative
Division.
--
F61X
An error is detected at the
Report compiling section
1) Execute U021 (Init memory) and check function.
2) Replace the control PWB and check function.
3) Retrieve the USBLOG and contact the Service Administrative
Division.
[Fault in the controller]
Turn the main power off and
on to solve the problem.
USBLOG is required for
investigation.
--
F63X
An error is detected at the
Device control section
1) Execute U021 (Init memory) and check function.
2) Replace the control PWB and check function.
3) Retrieve the USBLOG and contact the Service Administrative
Division.
--
F68X
An error is detected at the
Storage device control
section
1) Execute U021 (Init memory) and check function.
2) Replace the control PWB and check function.
3) Retrieve the USBLOG and contact the Service Administrative
Division.
System error F684 means the
overwritting error with the hard
disk security kit
--
2-3-15
