Utax P-4035 MFP

2NM/2NX/2NY/2NZ/2P0/2P6
1-2-22
6. Connect the USB connector to the USB
interface slot.
7. Fix the IC card reader holder using a
screw.
8. Refit all the removed parts.
Figure 1-2-40
9. Affix a label on the ICcar reader cover
aligning it with the positioning mark.
Figure 1-2-41
Screw
IC card reader holder
Operation panel assembly
USB connector
Label
Positioning mark
IC card reader cover
Operation
panel assembly
