Utax P-4530DN Service Manual

2LV/2L1/2L2/2MS/2MT-6
No.
Content
Check procedure & check point
Remark 1
P-4030D, P-4030DN, P-4530DN,
P-5030DN, P-6030DN
F13X
An error is detected at the
Panel control section
1) Check connection of the harness (Panel - Main board) and connectors and check
function.
2) Format the HDD and check function. (U024 FULL formatting) (*1)
3) Execute the U021 Memory initializing to initialize the controller backup memory and
check function.
4) Replace the panel board and check function. (*2)
5) Replace the main board and check function.
6) Retrieve the USBLOG and contact the Service Administrative Division. (*1)
(*1) For the HDD standard model only.
(*2) For the model separating the main/panel PWBs.
Check procedure is partly corrected as below.
1) Format the SSD and check function.([Formatting SSD)
2) (Not applicable)
4) Replace the SSD and check function.
F14X
An error is detected at the FAX
control section
1) Check connection of the harness (FAX - Main board) and connectors and check
function.
2) Format the HDD and check function. (U024 FULL formatting) (*1)
3) Execute the U021 Memory initializing to initialize the controller backup memory and
check function.
4) Execute the U671 Clear FAX back up data (FAX DIMM clear) and check function.
(*3)
(Take cae of the received data since it is cleared)
5) Replace the FAX_DIMM and check function.
6) Replace the FAX board and check function.
7) Replace the main board and check function.
8) Retrieve the USBLOG and contact the Service Administrative Division. (*1)
(*1) For the HDD standard model only.
(*3) For the models using the main PWB with the flash for the FAX data.
-
F15X
An error is detected at the
authentication device control
section
1) Check connection of the harness (Authentication device - Main board) and
connectors and check function.
2) Format the HDD and check function. (U024 FULL formatting) (*1)
3) Execute the U021 Memory initializing to initialize the controller backup memory and
check function.
4) Replace the main board and check function.
5) Replace the HDD and check function. (*1)
6) Retrieve the USBLOG and contact the Service Administrative Division. (*1)
(*1) For the HDD standard model only.
Authentication device: Card
Reader, etc.
Check procedure is partly corrected as below.
2) Format the SSD and check function.([Formatting SSD)
3) (Not applicable)
5) Replace the SSD and check function.
[Main/Engine - USB Host Interface]
Main board: YC10 (USB Host at the machine rear side)
Engine board: YC23 (USB Host under the operation panel)
F16X
An error is detected at the
KMAS control section
1) Check connection of the harness (KMAS - Main board) and connectors and check
function.
2) Format the HDD and check function. (U024 FULL formatting) (*1)
3) Execute the U021 Memory initializing to initialize the controller backup memory and
check function.
3) Replace the main board and check function.
4) Replace the HDD and check function. (*1)
5) Retrieve the USBLOG and contact the Service Administrative Division. (*1)
(*1) For the HDD standard model only.
F17X
An error is detected at the print
data control section
1) Format the HDD and check function. (U024 FULL formatting) (*1)
2) Execute the U021 Memory initializing to initialize the controller backup memory and
check function.
3) Replace the main board and check function.
4) Replace the HDD and check function. (*1)
5) Retrieve the USBLOG and contact the Service Administrative Division. (*1)
(*1) For the HDD standard model only.
Check procedure is partly corrected as below.
1) Format the SSD and check function.([Formatting SSD)
2) (Not applicable)
4) Replace the SSD and check function.
2-4-14
