Utax P-4530DN Service Manual

2LV/2L1/2L2/2MS/2MT
1-4-4
0511 Multiple sheets of jam The registration sensor 2 (RS2) does not turn off
during paper feed from cassette 1.
B
0512 PF feed sensor 1 (PFPFS1) does not turn off dur-
ing paper feed from cassette 2.
B
0513 PF feed sensor 2 (PFPFS2) does not turn off dur-
ing paper feed from cassette 3.
B
0514 PF feed sensor 3 (PFPFS3) does not turn off dur-
ing paper feed from cassette 4.
B
0515 PF feed sensor 4 (PFPFS4) does not turn off dur-
ing paper feed from cassette 5.
B
0518 The registration sensor 2 (RS2) does not turn off
during paper feed from duplex section.
B
0519 The registration sensor 2 (RS2) does not turn off
during paper feed from MP tray.
B
0529 No paper feed of jam
(Bulk feeder)
The registration sensor 2 (RS2) does not turn on
during paper feed from bulk feeder.
D
0539 Multiple sheets of jam
(Bulk feeder)
The registration sensor 2 (RS2) does not turn off
during paper feed from bulk feeder.
B
1403 PF feed sensor 1 non arrival
jam
PF feed sensor 1 (PFPFS1) does not turn on dur-
ing paper feed from cassette 3.
E
1404 PF feed sensor 1 (PFPFS1) does not turn on dur-
ing paper feed from cassette 4.
E
1405 PF feed sensor 1 (PFPFS1) does not turn on dur-
ing paper feed from cassette 5.
E
1413 PF feed sensor 1 stay jam PF feed sensor 1 (PFPFS1) does not turn off dur-
ing paper feed from cassette 3.
E
1414 PF feed sensor 1 (PFPFS1) does not turn off dur-
ing paper feed from cassette 4.
E
1415 PF feed sensor 1 (PFPFS1) does not turn off dur-
ing paper feed from cassette 5.
E
1604 PF feed sensor 2 non arrival
jam
PF feed sensor 2 (PFPFS2) does not turn on dur-
ing paper feed from cassette 4.
F
1605 PF feed sensor 2 (PFPFS2) does not turn on dur-
ing paper feed from cassette 5.
F
1614 PF feed sensor 2 stay jam PF feed sensor 2 (PFPFS2) does not turn off dur-
ing paper feed from cassette 4.
F
1615 PF feed sensor 2 (PFPFS2) does not turn off dur-
ing paper feed from cassette 5.
F
1805 PF feed sensor 3 non arrival
jam
PF feed sensor 3 (PFPFS3) does not turn on dur-
ing paper feed from cassette 5.
G
1815 PF feed sensor 3 stay jam PF feed sensor 3 (PFPFS3) does not turn off dur-
ing paper feed from cassette 5.
G
Code Contents Conditions
Jam
location*
*: Refer to figure 1-4-1 for paper jam location (see page 1-4-1).
