Utax P-4530DN Service Manual

2LV/2L1/2L2/2MS/2MT
1-4-5
4002 Registration sensor 2 non
arrival jam
The registration sensor 2 (RS2) does not turn on
during paper feed from cassette 2.
B
4003 The registration sensor 2 (RS2) does not turn on
during paper feed from cassette 3.
B
4004 The registration sensor 2 (RS2) does not turn on
during paper feed from cassette 4.
B
4005 The registration sensor 2 (RS2) does not turn on
during paper feed from cassette 5.
B
4012 Registration sensor 2 stay
jam
The registration sensor 2 (RS2) does not turn off
during paper feed from cassette 2.
B
4013 The registration sensor 2 (RS2) does not turn off
during paper feed from cassette 3.
B
4014 The registration sensor 2 (RS2) does not turn off
during paper feed from cassette 4.
B
4015 The registration sensor 2 (RS2) does not turn off
during paper feed from cassette 5.
B
4101 Registration sensor 3 non
arrival jam
The registration sensor 3 (RS3) does not turn on
during paper feed from cassette 1.
B
4102 The registration sensor 3 (RS3) does not turn on
during paper feed from cassette 2.
B
4103 The registration sensor 3 (RS3) does not turn on
during paper feed from cassette 3.
B
4104 The registration sensor 3 (RS3) does not turn on
during paper feed from cassette 4.
B
4105 The registration sensor 3 (RS3) does not turn on
during paper feed from cassette 5.
B
4108 The registration sensor 3 (RS3) does not turn on
during paper feed from duplex section.
B
4109 The registration sensor 3 (RS3) does not turn on
during paper feed from MP tray.
B
Code Contents Conditions
Jam
location*
*: Refer to figure 1-4-1 for paper jam location (see page 1-4-1).
