5.7.4 PO2 Control Mode Turning On
Sequence of PO2 Control Mode turning on:
connect the Oxygen cells' cable with AV1 connector;
Switch AV1 into CCR mode (See Menu item ->switch OC/CCR );
In this mode ->CellsControl SubMenu becomes available.
Enter ->CellsControl SubMenu to set required Oxygen cells ON;
Save setting by pressing YES :
With at least one Oxygen cell activated, AV1 will automatically offer to calibrate.
ALWAYS KEEP THE CONNECTOR CLEAN!
Do NOT leave the port open without seal or AV1 connected!
Try to minimize a number of connections/disconnectons!
NOTE!
Waterproof sealing of this connection is reached via O-ring
inside the AV1 Fischer connector port.
Always monitor and keep the connection clean!
