VAC D500 - Option Module Wiring Capacities; Wire Cross-Sections and Capacities

29
Option modules
Cross section
Rigid / flexible wires 0.14 to 1.5 mm
2
(AWG26 to AWG17)
Flexible with wire end sleeve no
plastic sleeve
0.25 to 1.5 mm
2
(AWG23 to AWG17)
Flexible with wire end sleeve
with plastic sleeve
0.25 to 1.5 mm
2
(AWG23 to AWG17)
Multi-wire connection capacity (two wire with the same cross-section)
Rigid / flexible wires 0.14 to 0.75 mm
2
(AWG26 to AWG20)
Flexible with wire end sleeve no
plastic sleeve
0.25 to 0.5 mm
2
(AWG23 to AWG22)
Flexible with wire end sleeve
with plastic sleeve
0.5 to 1 mm
2
(AWG21 to AWG18)
Limit switch with proximity switches or 24 V microswitches
Rigid wire 0.14 to 1.5 mm
2
(AWG26 to AWG17)
Flexible wire 0.14 to 1.0 mm
2
(AWG26 to AWG18)
Flexible with wire end sleeve no
plastic sleeve
0.25 to 0.5 mm
2
(AWG23 to AWG22)
Flexible with wire end sleeve
with plastic sleeve
0.25 to 0.5 mm
2
(AWG23 to AWG22)
