VAC D500 - Parameter Descriptions: Range Settings (Continued); Working Range Configuration

56
… 9 Operation
… Parameter descriptions
Menu / parameter Value range Description
Device Setup / Range Settings (continued)
Upper Working Rng 0.0 to 100.0 % The working range can be configured to be smaller than the maximum mechanical working range. The
set point range always refers to the configured working range. Use this parameter to specify the lower
limit of the working range.
CAUTION
Danger of crushing!
This function is only active in control mode. In the event of a power supply failure (electric or
pneumatic), and in manual mode, the mechanical end positions are approached.
• Do not reach into the adjustment mechanism.
Lower Working Rng 0.0 to 100.0 % The working range can be configured to be smaller than the maximum mechanical working range. The
set point range always refers to the configured working range. Use this parameter to specify the upper
limit of the working range.
CAUTION
Danger of crushing!
This function is only active in control mode. In the event of a power supply failure (electric or
pneumatic), and in manual mode, the mechanical end positions are approached.
• Do not reach into the adjustment mechanism.
