Vacon 20 User Manual

6
vacon • 16 Communications
Local contacts: http://drives.danfoss.com/danfoss-drives/local-contacts/
General status word (output process data)
Information about the status of the device and messages is indicated in the General status word. The
General status word is composed of 16 bits the meanings of which are described in the table below:
Actual speed (output process data)
This is actual speed of the AC drive. The scaling is -10000...10000. The value is scaled in percentage
of the frequency area between set minimum and maximum frequency.
Control word (input process data)
The three first bits of the control word are used to control the AC drive. By using control word it is
possible to control the operation of the drive. The meanings of the bits of control word are explained
in the table below:
Speed reference (input process data)
This is the Reference 1 to the AC drive. Used normally as Speed reference. The allowed scaling is
0...10000. The value is scaled in percentage of the frequency area between the set minimum and
maximum frequencies.
Table 11. General status word (output process data)
Bit
Description
Value = 0 Value = 1
B0, RDY Drive not ready Drive ready
B1, RUN Stop Run
B2, DIR Clockwise Counter-clockwise
B3, FLT No fault Fault active
B4, W No alarm Alarm active
B5, AREF Ramping Speed reference reached
B6, Z - Drive is running at zero speed
B7, F - Fieldbus control active
B8 - B12 - -
Bit
Control Place
I/O PC tool Keypad Fieldbus
B131000
B140110
B150101
Table 12. Control word (input process data)
Bit
Description
Value = 0 Value = 1
B0, RUN Stop Run
B1, DIR Clockwise Counter-clockwise
B2, RST Rising edge of this bit will reset active fault
B5 Not used

Vacon 20 Specifications

General

Communication Options	Modbus, CANopen, PROFIBUS, Ethernet
Protection Class	IP20
Power Range	0.25 to 18.5 kW
Control Method	Scalar control, Vector control
Ambient Temperature	-10°C to +50°C
