128
PR-23 instrucon manual
9.8.7 PR-23-M/MS mounng specics
           
       
          
            
4.72
120.0
2.97
75.5
1.24
31.5
7.11
180.7
1 2 3
4
4
G1/2" or
NPT 1/2"
G1/2" or
NPT 1/2"
Suppor sensor here
Note!
Cable downwards
Grounding
screw
Note! Keep sensor
axle horizontal
Figure 9.28 G1/2" female process connecon (mm [in])
