PR-23 instrucon manual
9.3.2 PR-23-AC mounng hardware model code
Elbow ow cells for PR-23-AC-62-HSS sensor
Model and descripon Model
AFC = Elbow ow cell AFC
Sensor connecon
-H = Sanitary 3A-clamp, 2½ inch -H
Material of construcon
SS = AISI 316 L SS
Process connecon
-H = Sanitary 3A-clamp -H
Pipe secon diameter
10 = 25 mm (1 inch) 10
15 = 40 mm (1½ inch) 15
20 = 50 mm (2 inch) 20
25 = 65 mm (2½ inch) (A) 25
30 = 80 mm (3 inch) (A) 30
40 = 100 mm (4 inch) (A) 40
Flow cell inlet type
-SI = Straight pipe -SI
-RI = Reduced pipe (cone) -RI
Polishing opon
-EP = Electropolished process weed parts (RA 0.38µm, 15 µ inch) -EP
(A) with -SI opon only
EHEDG Cered Elbow Flow Cells, connecon Sanitary 3A-clamp 2½ inch
Model and descripon Model
AFC = Elbow ow cell AFC
Sensor connecon
-H = for Sanitary 3A-clamp, 2½ inch -H
Material of construcon
SS = AISI 316 L SS
Process connecon
-H = Sanitary 3A-clamp -H
Pipe secon diameter
20 = 50 mm (2 inch) 20
Flow cell inlet type
-SI = Straight pipe -SI
