Vaisala K-PATENTS PR-23 Series User Manual

9 Sensor specicaons
133
9.9.4 PR-23-W mounng specics
           
             
           
             
           
 
A
D
E
B
F
C
51Nm
37lbs.ft.
60Nm
44lbs.ft.
53Nm
39lbs.ft.
Related drawing.
No modification permitted
without the approval of
the authorized person.
PR-23-W SVB 050
PR-23-W SVB 080
PR-23-W SVB 100
Appr.
Drawn
Drawing number
Drawing description
Mass
General tolerances
DIM
-
29.01.2015 HS
29.01.2015 TL
-
Revision
DIM450 C
Scale
1:3
PR-23-W & SVB
Material
Figure 9.30 PR-23-W mounng
