10 Indicang transmier DTR specicaons

155

DTR/STR-R-B3/B4-AL-AC/DC

Unclassiﬁed area

Zone 1/2Zone 0/1

Power

mA-Output

4-20mA

100-240VAC

24VDC

PR-23...IA

# drw Description Supplied by

1 5675 DTR/STR-R-B3/B4-AL-AC/DC K-Patents

2 PR-23...IA K-Patents

3 K-Patents

4 mA cable Customer

5 Mains power supply cable Customer

Figure 10.7 STR-R-B3/B4-AL-AC/DC

Default Chapter5
