Compa II series Technical data
07.15 Operating manual 15
3 Technical data
Compa II
103/8 T
Compa II
104/8
Compa II
106/12
Compa II
106/24
Compa II
108/12 T
Compa II
162/12
Compa II
162/12 T
Print resolution 203 dpi 203 dpi 300 dpi 600 dpi 300 dpi 300 dpi 300 dpi
Max. print speed 200 mm/s 200 mm/s 200 mm/s 150 mm/s 200 mm/s 150 mm/s 150 mm/s
Print width 104 mm 104 mm 105.7 mm 105.6 mm 108.4 mm 162.6 mm 162.6 mm
Passage width 116 mm 116 mm 116 mm 116 mm 116 mm 176 mm 176 mm
Printhead Flat Type
Labels
Labels, continuous rolls
or fan-fold
paper, cardboard, textile, synthetics
Max. material weight max. 220 g/m² (larger on demand)
Min. label width 12 mm
Min. label height
Standard 5 mm
Cutter/dispenser mode 25 mm
Max. label height
(larger on demand)
6000 mm 6000 mm 3000 mm 750 mm 3000 mm 2000 mm 2000 mm
Max. roll diameter
Internal unwinder 200 mm
Internal rewinder 145 mm (option)
Core diameter 40 mm / 75 mm (option)
Winding outside or inside
Label sensor transmission and reflexion from below
Transfer ribbon
Ink outside or inside
Max. roll diameter Ø 80 mm
Core diameter 25.4 mm / 1″
Max. ribbon length 300 m
Max. width 110 mm / 170 mm (Compa II 162)
Dimensions (mm)
Width x height x depth 242 x 274 x 446 / 302 x 274 x 446 (Compa II 162)
Weight 10 kg / 14 kg (Compa II 162)
Electronics
Processor High Speed 32 Bit
RAM 16 MB / 64 MB (on demand)
Slot for Compact Flash card Type I
Battery cache for Real-Time clock (storage of data with shut-down)
Warning signal acoustic signal when error
Interfaces
Serial RS-232C (up to 115200 Baud)
Parallel Centronics (SPP)
USB 2.0 High Speed Slave
Ethernet 10/100 Base T, LPD, RawIP-Printing, DHCP, HTTP, FTP
2 x USB Master connection for external USB keyboard and memory stick
WLAN (option) card 802.11b/g WEP/WPA PSK (TKIP)
Operation data
Power supply 110-230 V / 50-60 Hz
Max. power consumption max. 150 VA
Operating temperature 5 … 35 °C
Humidity max. 80% (non-condensing)
1
for thermal direct
2
for thermal transfer
