Compa II series Options
07.15 Operating manual 59
7 Options
7.1 Cutter
CAUTION!
Risk of injury, particularly during maintenance, the cutter
blades are sharp!
Switch off the before attaching the cutter!
The cutter may only be used when it is mounted on
the printer!
Do not try to cut any materials which exceed the
maximum width or thickness specifications.
Do NOT touch the area of the moving blades!
Switch on the label printer and the display shows the main menu.
Press key
to access the function menu.
Press key
as long as you arrive the Cutter menu.
Press key
to select the menu.
NOTICE!
The menu item cutter is only displayed if the printer recognizes
the option via cutter photocell when switching on the printer.
In the upper line of display, the cutter mode can be selected.
In the line below, the cutter offset (approx. 20 mm) can be set.
Press key
to change to the next operating mode.
Off:
The print order is processed without cutting.
Without backfeed:
A cut is effected after each label.
We recommend using this operating mode if no data which is to print
is in the upper part of the label.
With backfeed:
A cut is effected after each label.
Interval with final cut:
A cut is effected after a fixed number of labels which you have to enter
at the print start and additionally at the end of the print order.
Interval without final cut:
A cut is effected after a fixed number of labels which you have to enter
at the print start. At the end of the printer order no cut is effected
except when the set interval comes to the end of the print order.
Final cut:
A cut is only effected at the end of the print order.
Operating modes
