Compa II series Installation
07.15 Operating manual 27
4.4 Initiation of the label printer
After switching on the label printer the main menu appears which
shows the printer type, current date and time.
Insert label material and transfer ribbon (see chapter 5. Loading
media, page 29).
Go to menu Label layout, select menu item Measure label and start
measuring (see chapter 6.4 Label layout, page 47).
Press key
to finish measuring.
NOTICE!
To enable correct measuring, at least two completed labels
have to be passed through (not for continuous labels).
During measuring the label and gap length small differences can
occur. Therefore the values can be set manually in menu Label
layout/Label and Gap.
