Function menu Compa II series
48 Operating manual 07.15
Press key
to arrive the next menu item.
In case an error occurs, indication after how many mm a message
appears in the display.
Value range:1 mm … 999 mm.
On: If a label is missed on the liner an error message is displayed.
Off: Missing labels are ignored, i.e. it is printed into the gap.
Press key
to arrive the next menu item.
The axis of reflection is in the middle of the layout. If the label width
was not transferred to the printer, automatically the default label width
i.e. the width of the printhead is used. It is recommended to use labels
with the same width as the printhead. Otherwise this can cause
problems in positioning.
Press key
to arrive the next menu item.
According to standard the label is printed ahead with a rotation of 0°. If
the function is activated, the label is rotated by 180° and printed in
reading direction.
Press key
to arrive the next menu item.
The adjustment of label is effected only after Flip/Rotate label, i.e. the
adjustment is independent of the functions Flip label and Rotate label.
Left: The label is aligned at the left-most position of printhead.
Centre: The label is aligned at central point of printhead.
Right: The label is aligned at right-most position of printhead.
Label error length
Synchronisation
Flip label
Rotate label
Alignment
