EXP 1: EXP 2: PatchVOL
PatchVOLMixGain
1
BPM: 120
Getting Started
Main Display Screen is the home page displayed right after the power is turned on. You can directly see the key
information and settings of the current patch.
A
J
B
C
D
E
F
H
I
G
. Patch number
. Patch name
. Patch volume monitor
. Patch BPM
. Patch volume
A
B
C
D
E
F
G
H
I
J
. EXP pedal state
. Patch state
. DRUM state
. Current footswitch setting
. Quick adjust paras
5
GP-200 includes 256 patches, with the first 100 (01-A~25-D) containing default factory parameters. When performing a
factory reset, you can separately reset these 100 patches to the default values.
Tap footswitch A, B, C, D, choose a patch you like. Tap footswitch BANK- to move back through the banks, and tap
footswitch BANK+ to move forward through the banks. When you switch a BANK, the LED ring on footswitch A, B, C, D
will light up to indicate the patch if you want to select one.
Select a patch
Screen Introduction
Main Display Screen
TUNER
Hold the [TAP] footswitch to activate the tuner mode.
In tuner mode, the LED screen will display the tuning
interface. When you pluck a string, the note will appear in
the center. Left of center is flat, and right of center is sharp.
As you tune your instrument towards the middle, the color
of the scale will change from red (out of tune) to yellow
(near pitch) to green (in tune).
Mode Back Pitch - Pitch +
Mode
Mute
Pitch
TUNER
Ÿ Turn Quick Access Knob 1 or tap footswitch A to select the work mode of the tuner:
◦ Thru: Your tune will be normal.
◦ Bypass: Eect chain will be bypassed, and you will only hear the dry guitar input sound.
◦ Mute: There will be no output.
Ÿ Turn Quick Access Knob 3 or tap footswitch C and D to change the standard A’s frequency ranged from 432Hz to
447Hz, with default set to 440Hz.
Ÿ Tap other footswitches or click BACK to return back to the Main Display screen.
